Zebra 83340 Z-Select 4000T labels provide a wide, narrow 4" x 1" format for shelf-edge labels, price strips and product barcodes. Ultra-smooth, white topcoated paper supports high-quality thermal transfer printing, while permanent acrylic adhesive holds labels in place for indoor retail and warehouse workflows. Perforated stock allows easy separation. A compatible thermal transfer ribbon is required and sold separately.

Each case contains 4 rolls of 2,260 labels, totaling 9,040 labels. Rolls have a 1" core and a 5" outer diameter.

Product specifications

• Manufacturer: Zebra
• Part number: 83340
• Secondary references: TT4010-5 / 10009529
• Series: Z-Select 4000T
• Print method: Thermal transfer
• Label width: 4" (101.6 mm)
• Label length: 1" (25.4 mm)
• Material: White, smooth topcoated paper
• Adhesive: Permanent acrylic-based adhesive
• Core diameter: 1" (25.4 mm)
• Roll outer diameter: 5" (127 mm)
• Labels per roll: 2,260
• Rolls per case: 4
• Labels per case: 9,040
• Perforated: Yes
• Ribbon: Required; sold separately

Material construction

Z-Select 4000T combines a 2.7 mil white topcoated paper facestock, a 0.5 mil permanent acrylic adhesive layer and a 2.5 mil, 40 lb. semi-bleached kraft liner. Total construction thickness is 5.7 mil ±10%. Its ultra-smooth surface supports high-quality thermal transfer printing, including high-speed applications with a suitable ribbon and printer setup.

Applications

Use the 4" x 1" format for shelf-edge identification, price strips, product barcodes, packaging identifiers and work-in-process tracking. Match the layout to your software and required information. This paper material is intended for indoor use and is not recommended for outdoor exposure.

Temperature and storage

• Minimum application temperature: 30°F (-1°C)
• Service temperature range: -65°F to 200°F (-54°C to 93°C)
• Optimal storage conditions: 72°F (22°C) at 50% relative humidity

Application temperature describes conditions when attaching the label. Service temperature describes exposure after application; the lower service rating is not a cold-surface application rating. Pre-test adhesion and print readability on the intended surface under actual operating conditions.

Printer fit and ribbon selection

Select a thermal transfer printer that accommodates the media width, 1" core, 5" roll diameter and material thickness. Check the exact model's media sensing and ribbon requirements; print width alone does not establish roll compatibility. Use a compatible wax or wax/resin ribbon in the correct dimensions, core and winding for your printer. Zebra's material sheet evaluates the 2000, 6000 and 6100 ribbon families; choose the appropriate ribbon configuration for your equipment and application.

Exposure guidance

Test the complete label-and-ribbon combination for the intended end use. Alcohol, ammonia, bleach, IPA, gasoline, grease, oil, acetone, MEK, TCE and xylene are not recommended exposures with the ribbon combinations evaluated in the material sheet. These paper labels are not a substitute for solvent-resistant or outdoor-rated media.

Frequently asked questions

What size is Zebra 83340?

Each individual label measures 4" wide by 1" long (101.6 x 25.4 mm).

How many labels are included?

Each roll contains 2,260 labels. A case contains 4 rolls, for a total of 9,040 labels.

Does this label require a ribbon?

Yes. Zebra 83340 is thermal transfer label stock and requires a compatible ribbon, sold separately.

What are the roll dimensions?

Each roll has a 1" core and a 5" outer diameter. Your printer must accommodate both dimensions and the media width.

Are these labels perforated?

Yes. Zebra 83340 is perforated for easy separation.

Will these fit any 4-inch Zebra printer?

The printer must support thermal transfer printing, the media width, a 1" core and a 5" roll diameter. Check its sensing and ribbon requirements for the exact configuration.

Can these labels be used outdoors?

Z-Select 4000T paper is not recommended for outdoor use. Choose outdoor-rated media for exterior exposure.

Can labels be applied at -65°F?

No. The minimum application temperature is 30°F (-1°C). The lower service-temperature rating is not an application temperature.
